Ebmpapst 6424 Fan

Name: Ebmpapst 6424 Fan
SKU: EMP0078056
Price: 31 USD
Availability: InStock

Stock:

SKU:{{ product.sku }}

Model: {{ product.model }}

weight: {{ product.weight }} Kilogram

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

Quantity:

Product Details

Brand:	Ebmpapst
MPN:	6424
Fan Type:	Tubeaxial
Voltage:	24VDC
Speed (RPM):	3400 RPM
Air Flow:	241.3 CFM (6.76m³/min)
Noise:	57.0 dB(A)
Termination:	2 Terminals
Width:	50.80mm
Features:	–
Series:	6400
Static Pressure:	–
Description:	FAN AXIAL 172X50.8MM 24VDC TERM
Size / Dimension:	Rectangular/Rounded – 172mm L x 150mm H
Moisture Sensitivity Level (MSL):	1 (Unlimited)
Bearing Type:	Ball
Approvals:	–
Voltage Range:	12 ~ 28VDC
Power (Watts):	18.00W
Operating Temperature:	-4 ~ 162°F (-20 ~ 72°C)
Material – Frame:	Aluminum
Material – Blade:	Polyamide (PA), Nylon, Fiberglass Reinforced
Lifetime @ Temp.:	75000 Hrs @ 40°C
Ingress Protection:	–
Current Rating:	–
Manufacturer:	ebm-papst Inc.
