ebm-papst MULTIFAN8314 Fan

Name: ebm-papst MULTIFAN8314 Fan
Brand: ebmpapst
SKU: EMP0079086
Price: 51 USD
Availability: InStock

Stock:

Brand: ebmpapst

SKU:{{ product.sku }}

Model: {{ product.model }}

weight: {{ product.weight }} Kilogram

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

Quantity:

Product Details

Brand:	Tubeaxial
Model:	MULTIFAN8314
RPM:	3300 RPM
Termination:	2 Wire Leads
Manufacturer:	ebm-papst Inc.
Width:	32.00mm
Air Flow:	31.8 CFM (0.890m³/min)
Features:	–
Series:	8300
Static Pressure:	–
Noise:	36.0 dB(A)
Description:	FAN AXIAL 80X32MM 24VDC WIRE
Voltage – Rated:	24VDC
Size / Dimension:	Square – 80mm L x 80mm H
Other Names:	381-1009
Moisture Sensitivity Level (MSL):	1 (Unlimited)
Bearing Type:	Ball
Approvals:	CE, CSA, UL, VDE
Voltage Range:	12 ~ 28VDC
Power (Watts):	2.50W
Operating Temperature:	-4 ~ 167°F (-20 ~ 75°C)
Material – Frame:	Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material – Blade:	Polyamide (PA), Nylon, Fiberglass Reinforced
Lifetime @ Temp.:	70000 Hrs @ 40°C
Ingress Protection:	–
Current Rating:	–
